ALLWIN photo printing machine, created the standard of similar products in Japan as the goal and painstakingly. Features:

1. piezoelectric picture quality comparable to similar pictures of Japan;

2. standard double-headed design, print, twice the speed of a single head;

3. automatically receiving, feeding structures;

4. infrared heating, air-dry system;

5. print format 186cm, with a print before, during and after heating;

6. machine-tested, stable and reliable, capable for mass production needs.



High quality--Printing quality and
output capacity advanced in industry

Double piezoelectric printheads with high quality and high output, highest resolution is

photographic printing quality.

Double piezoelectric printheads

Double piezoelectric printheads can achieve high speed, high quality and better durability

which Epson piezoelectric printheads are famous for. It can accurately position each ink

droplet and accurately control the ink level. Each color has  two ink channels (360 nozzles

for each color) which can obtain much higher speed.

3 separate heaters

1.pre heater: enhance the ink adhesion;
2.Bed heater: solidify ink droplet shape;
3.Rear heater: speed up ink drying.


Variable Ink-drop technology,photographic quality printing.

There are three different sizes of ink-drop, users can change the ink-drop size to print

according to the demand of color gradient, which makes picture  higher resolution and

better sense of depth layout.

Infrared heating system

1. It could set 1.8m, 2.5m and 3.2m heating width freely;

2. Adjustable heating temperature for media surface from 35 to 80°C;

3. Adjustable drying fan power level;

4. Print in 120m2/h, the image will dry simultaneously;

5. External infrared heating system to replace the platform heating system;

6.Through infrared heating, it will get stronger colour adhesion to get longer weather resistance.

7.Heater automatically stops when printing pauses, heater automatically works when printing starts.

Note: this system works with inserted feeding and automatic collecting system, it can achieve unattended printing.

Photos:
